Miele WTF 130 WPM User Manual

Installation and connection
93
Connection to the water supply
The washer-dryer should be connected
to the mains water supply in accord-
ance with current local and national
safety regulations. The German author-
ities do not require it to have a non-re-
turn valve as the washing machine has
been designed to comply with DIN reg-
ulations.
The machine is designed to operate
with a flow pressure of between 100
and 1000kPa. If it is higher than
1000kPa it is essential to fit a pressure
reducing valve.
Connection to the mains water supply
should incorporate a mains stopcock
with 3/4" threaded union. The stopcock
should be fitted by a qualified plumber.
 The screw connection is subject
to mains water pressure.
Turn on the stopcock slowly and
check for leaks. Correct the position
of the washer and union if appropri-
ate.
The washer-dryer is not suitable for
connection to a hot water supply.
Maintenance
Only use a genuine Miele hose that has
been tested to withstand pressure of at
least 14,000 kPa should you ever need
a replacement.
The dirt filter in the open end of the
inlet hose must not be removed.
Extension hose
A 1.5 metre long (metal) extension hose
is available from your Miele dealer or
the Miele Spare Parts Department as an
optional extra.

Miele WTF 130 WPM Specifications

General

Door hinge	Right
Control type	Buttons, Rotary
Loading type	Front-load
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Half-load	-
Drying capacity	4 kg
Washing capacity	7 kg
Delay start (max)	24 h
Spin-drying class	A
Maximum spin speed	1600 RPM
Noise level (wash)	- dB
Water consumption washing per cycle	90 L
Energy consumption washing per cycle	- kWh
Water consumption washing & drying per cycle	- L

Weight and Dimensions

Depth	636 mm
Width	596 mm
Height	850 mm
