Inlet for Peristaltic Chemical Supplies and Water
PELLERIN MILNOR CORPORATION
Table 1: Parts List—Inlet for Peristaltic Chemical Supplies and Water
Find the assembly for your machine and the letter shown in the "Item" column. The components for your
machine will show this letter or the word "all" in the "Used In" column. The numbers shown in the "Item"
column are those shown in the illustrations.
Used In Item Part Number Description/Nomenclature Comments
Assemblies
A ZBXJFVE20A 3626X8J H+C H2O INLET 36026X8J,X8W,X8R
B ZBXJFVE20A 42X H+C WATER VALVES 42026X7J,X7W,X7R
42032X7J,X7W,X7R
none
Components
all 1 02 03588M Inlet manifold
all 2 02 03588K Cover
all 3 02 03195A Mounting bracket
all 4 02 02930 Mounting plate
all 5 02 03588X Inlet manifold hose
all 6 27A074 Clamp, 2+1/16-3"
A 7 60E008A Flexible tubing, .75"X1.025"
B 7 60E014R Flexible tubing, 1.25X1.75
all 8 27A090 Clamp, 13/16-1.5"
all 9 60E006C Flexible tubing, .5X.75
all 10 27A040 Clamp, 7/16-25/32
all 11 600000000000 Flexible tubing, 1"X1.312
all 13 15N110H Bolt, M6-1X25MM
all 14 15G004HB Nut, M6-1, 0.8-4MM
all 15 15K031 Bolt, 1/4-20X1/2
all 16 27A031C U-bolt, 1.25, 5/16-18
all 17 15G196 Nut, 5/16-18
all 18 02 10539 Spacer
all 19 12K108 Mounting bracket
all 20 15K041 Bolt, 1/4-20X1
all 21 15G178 Nut, 1/4-20
all 22 20C009CA Adhesive #3032
— End of BIMXCM11 —
