Pneumatic Schematic
PELLERIN MILNOR CORPORATION
Table 1: Parts List— Pneumatic Schematic
Find the assembly for your machine and the letter shown in the "Item" column. The components for your
machine will show this letter or the word "all" in the "Used In" column. The numbers shown in the "Item"
column are those shown in the illustrations.
Used In Item Part Number Description/Nomenclature Comments
Assemblies
AVA75X7J Assembly
A 3626X8J,X8W 4226X7J,X7W
4232X7J,X7W USA-made
models only
B 3626X8J,X8W 4226X7J,X7W
4232X7J,X7W China-made
models only
Components
A 1 X3 01507D Manifold
A 2 03 LF1X5K Manifold, Retainer
all 3 96R302B71 Pilot valve, 1/8", Usually open, 240V50/60
all 4 96R301B71 Pilot valve 1/8", Usually closed, 240V50/60
all 5 09N082A Pressure switch, 62#
B 6 98CX880115 Water valve, 1-1/4",air operated 4226X7J,X7W 4232X7J,X7
B 7 96D0009E Steam valve, 3/4", air operated
B 8 98CMCR3604 Drain valve, air operated
B 9 98CX880511 Air regulator
— End of BIMXCM21 —
151
