Components, Shell Doors
PELLERIN MILNOR CORPORATION
Table 1: Parts List—Components, Shell Doors
Find the assembly for your machine and the letter shown in the "Item" column. The components for your
machine will show this letter or the word "all" in the "Used In" column. The numbers shown in the "Item"
column are those shown in the illustrations.
Used In Item Part Number Description/Nomenclature Comments
Assemblies
A GSD4226X Installation Group 42026X7J,X7W,X7R
42032X7J,X7W,X7R
B GSD42001R Installation Group Recirculation piping
Components
all 1 03 48048A Frame, Door, 26"
all 2 W2 23507A Striker
all 3 02 23507E Cover
all 4 02 21181A Bracket
all 5 02 11162B Hinge pin
all 7 03 48060 Door outer channel
all 8 03 48061 Door inner channel
all 9 02 15633A Door handle
A 10 02 15633 Adjustment plate 10 GA
B 10 02 15633B Adjustment plate 10 GA SS
all 11 02 15633S Adjustment plate 16 GA
all 12 SA 15 028 Assembly, Latch
all 13 15N117 Bolt, 10-24X3/8
all 14 15U160 Washer, Lock, #10
all 15 02 15016 Shim
all 16 02 10391A Mounting plate
all 17 X2 15016A Hinge
all 18 15U349 Washer, Flat, Nylon, 1.93X1.25
all 19 15K221 Bolt, 5/8-11X2
all 20 15U315 Washer, Lock, 5/8"
all 21 09RM01212S Switch
all 23 15K145 Bolt, 1/2-13X3/4
all 24 15U310 Washer, Lock, 1/2
all 25 15U285 Washer, Flat, 1/2"
all 26 15U260 Washer, Lock, 3/8"
all 27 15K096A Bolt, .3/8-16X1
all 28 53A500 Pipe fitting
all 29 53A501 Pipe fitting
all 30 53A059A Pipe fitting
all 31 53A005B Pipe fitting
all 32 53A031B Pipe fitting
all 33 15K095 Bolt, 3/8-16X1
all 34 15U255 Washer, Lock, 3/8
all 35 60B090 Pneumatic bellows actuator
all 39 54JH13125C Split collar
all 40 60C075 Bumper, 2+1/2"
92
