Recirculation Piping
PELLERIN MILNOR CORPORATION
BIMXCM27 (Published) Book specs- Dates: 20120622 / 20120622 / 20120625 Lang: ENG01 Applic: MXC
Recirculation Piping
Figure 1: Installed views
Recirculation piping
Legend
A. Reuse water through the recirculation pump to the door
B. Reuse water through the recirculation pump to the tank
.
120
