Five Compartments for Dry Chemical Supplies
PELLERIN MILNOR CORPORATION
Table 1: Parts List—Five compartments for dry chemical supplies
Find the assembly for your machine and the letter shown in the "Item" column. The components for your
machine will show this letter or the word "all" in the "Used In" column. The numbers shown in the "Item"
column are those shown in the illustrations.
Used In Item Part Number Description/Nomenclature Comments
Assemblies
A GWS3626X5 Installation Group 36026X8J,X8W,X8R
B GWS4226X5 Installation Group 42026X7J,X7W,X7R
C GWS4232X5 Installation Group 42032X7J,X7W,X7R
D AWS3626X5 Assembly 36026X8J,X7W,X8R
E AWS4226X5 Assembly 42026X7J,X7W,X7R
42032X7J,X7W,X7R
Components
A 1 02 13585B Cover
B 1 02 23585B Cover
C 1 02 24525C Cover
all 2 02 03870D Flexible tubing, 2"X 14"
all 2 02 03870 Flexible tubing, 2"X24"
all 3 27A070 Hose clamp, T-bolt, 1.94"-2.25"
all 4 W2 21162B Weldment
A 5 02 13590 Bracket
BC 5 02 23590 Bracket
A 6 02 13590A Bracket
BC 6 02 23590A Bracket
A 7 02 13591 Cover
BC 7 02 23591 Cover
A 8 02 13592 Cover
BC 8 02 23592 Cover
all 9 02 09100 Piece part
all 10 SA 16 034C Valve assembly
all 11 15K095 Bolt, 3/8-16X1
all 12 15G198 Nut, 3/8-16
all 13 SA 09 047 Cover
all 14 27A017 Strap, 1/2"
all 15 15N117 Bolt, 10-24X3/8
all 16 15U160 Washer, Lock, #10
all 17 24G018N Washer, Nylon, .194
all 18 15G130 Nut, 10-24
all 19 15K086 Bolt, 3/8-16X3/4
all 20 15U260 Washer, Lock, 3/8
all 21 24G030N Washer, Nylon, .379
all 22 15G200SS Nut, 3/8-16
all 23 15K017 Bolt, 10-24X1/2
all 24 15P100 Bolt, #8X3/8
all 25 15N146 Bolt, 10-24X1
all 26 15U135 Washer, Flat, 10-.437X.203X.04
all 27 51X017 Union, 1/2"
136
