Milnor 42026X7J User Manual

PELLERIN MILNOR CORPORATION
Table 1: Parts List—Bearing Housing Components
Find the assembly for your machine and the letter shown in the "Item" column. The components for your
machine will show this letter or the word "all" in the "Used In" column. The numbers shown in the "Item"
column are those shown in the illustrations.
Used In Item Part Number Description/Nomenclature Comments
Assemblies
A ABN42001 Assembly, Front bearing 4232F7R, F7S
4226X7J, X7W, X7R
4232X7J,X7W, X7R
B ABM42001 Assembly, Bearing housing 4232F7R, F7S
4226X7J, X7W, X7R
4232X7J,X7W, X7R
Components
all 1 X2 21040 Bearing housing
all 2 X2 21043 Shaft
all 3 02 21044 Seal sleeve
all 4 24S137 Seal 5.188X6.75X.5
all 5 02 21049 Cover
all 6 02 21048 Gasket
all 7 X2 21041 Seal holder
all 8 60C176 O-ring 10X1/4"
all 9 60C169 O-ring 7+3/4x1/8
all 10 X2 21042 Bearing holder
all 11 02 21045 Seal holder
all 12 02 21046 Spacer
all 13 02 21045A Seal holder
all 14 24S135 Seal 5.188X6.5X.5
all 15 24S053 Seal 2.625X3.625X.437
all 16 02 21047 Gasket
all 17 20C011C Adhesive, LOC#60941
all 18 54AT101190 Bearing
all 19 54A050S Bearing
all 20 56ATW14 Washer
all 21 56AHW114 Washer
all 22 56AHN14 Bearing locknut
all 23 15K112 Bolt, 3/8-16X1+1/2
all 24 15U260 Washer, Lock, 3/8
all 25 15K176A Bolt, 1/2-13X1.75
all 26 15U317B Washer, 1.062X.531X.115
all 27 53A031B Pipe fitting , 90 degree, .25X1/8
all 28 53A500 Pipe fitting
all 29 53A501 Pipe fitting
all 30 53A059A Pipe fitting
all 31 5SP0CFESSV Plug, Square head with vent, 1/8
all 32 20C012D Adhesive, LCT#68015 10CC
all 33 20C006P Primer, #7649 LCT#21348-4
all 34 20C007H Threadlock, Removable, #24221
all 35 20C041 Silicone, High temperature, 10.2OZ
77

Milnor 42026X7J Specifications

General

Brand	Milnor
Model	42026X7J
Category	Washer
Language	English
