Milnor 42026X7J User Manual

Drive Motor Installation
PELLERIN MILNOR CORPORATION
Table 1: Parts List— Drive Motor Installation
Find the assembly for your machine and the letter shown in the "Item" column. The components for your
machine will show this letter or the word "all" in the "Used In" column. The numbers shown in the "Item"
column are those shown in the illustrations.
Used In Item Part Number Description/Nomenclature Comments
Assemblies
A ADB3626X7 Installation Group 3626X7 3626X8J,X8W,X8R
B ADB4226X Installation Group 4226X, 4232X 4226X7J,X7W,X7R
4232X7J,X7W,X7R
Components
all 1 02 21061B Mounting plate
all 2 02 21061 Mounting plate
all 3 02 21062 Plate
all 4 W2 13504 Piece part
all 4 W2 23504 Weldment
A 5 W2 13504A Piece part
B 5 W2 23504A Piece part
all 6 15B186 Bolt, 5/8-11x7
all 7 15G238 Nut, 5/8
all 8 17W030 Washer, Spherical, 5/8
all 9 15U315 Washer, Lock, 5/8
all 10 15K162 Bolt, 1/2-13X1.5
all 11 15U490 Washer, 1+1/2X17/32X1/4
all 12 15U300 Washer, Lock, 1/2
all 13 15G230 Nut, 1/2-13
all 14 15K180 Bolt, 1/2-13X2
all 15 15K173A Bolt, 1/2-13X1.75
all 16 15U280 Washer
— End of BIMXCM03 —
