Bearing Housing Components
4226X7J,X7W,X7R 4232X7J,X7W,X7R 4232F7R,F7S
Figure 1: Bearing Housing Components
Cross Section
Legend
AA. Cross Section
C. Detail view of the bearing housing front
D. Detail view of the bearing housing rear
P. Water outlet
Q. Vent
R. Grease inlet for the front bearing
S. Grease inlet for the rear bearing
.
