Milnor 42026X7J User Manual

Torque Requirements for Fasteners
PELLERIN MILNOR CORPORATION
Table 4: Torque Values for Plated Fasteners Larger Than 5/16-inch Diameters and No Lubricant
Dimension
The Grade of the Bolt
Grade 2
Grade 5
Grade 8
Grade BC
Pound-feet N-m Pound-feet N-m Pound-feet N-m Pound-feet N-m
3/8 x 16
15
20
23
31
33
44
29
38
3/8 x 24 17 23 26 35 37 49 -- --
7/16 x 14 24 32 37 50 52 71 46 61
7/16 x 20 27 36 41 55 58 78 -- --
1/2 x 13
37 49 56 76 80 106 70 93
1/2 x 20
41
55
64
85
90
120
--
--
9/16 x 12 53 70 81 110 115 153 101 134
9/16 x 18 59 79 91 122 128 174 -- --
5/8 x 11 73 97 113 150 159 212 139 186
5/8 x 18
83 110 127 172 180 240 -- --
3/4 x 10
129
173
200
266
282
376
246
329
3/14 x 16 144 192 223 297 315 420 -- --
7/8 x 9 125 166 322 430 455 606 398 531
7/8 x 14 138 184 355 474 501 668 -- --
1 x 8
188 250 483 644 682 909 597 796
1 x 12
205
274
528
716
746
995
--
--
1 x 14 210 280 542 735 765 1037 -- --
1 1/8 x 7 266 354 595 807 966 1288 845 1126
1 1/8 x 12 298 404 668 890 1083 1444 -- --
1 1/4 x 7
375 500 840 1120 1363 1817 1192 1590
1 1/4 x 12
415
553
930
1261
1509
2013
--
--
1 3/8 x 6 491 655 1102 1470 1787 2382 1564 2085
1 3/8 x 12 559 758 1254 1672 2034 2712 -- --
1 1/2 x 6 652 870 1462 1982 2371 3161 2075 2767
1 1/2 x 12
733 994 1645 2194 2668 3557 -- --
1.1.2.
With a Threadlocker
Table 5: Threadlocker by the Diameter of the Bolt (see Note 2)
LocTite Product
Dimension
1/4-inch
1/4- to 5/8-inch
5/8- to 7/8-inch
1-inch +
LocTite 222 OK
LocTite 242
OK
LocTite 262
OK
LocTite 272 High temperature
LocTite 277 OK
Note 2: The acceptable bolt size ranges for various LocTite
®
threadlocking products is the LocTite
manufacturer’s general recommendation. Specific applications sometime require that a LocTite product is
applied to a bolt size outside the ranges shown here. For example, Milnor specifies LocTite 242 for use on
certain 1" bolt applications and has confirmed this usage with the LocTite manufacturer. You may see
variances such as this in the documentation for specific machine assemblies.
