Milnor 42026X7J User Manual

Torque Requirements for Fasteners
PELLERIN MILNOR CORPORATION
Table 9: Torque Values if You Apply LocTite 272 (High-Temperature)
Dimension
The Grade of the Bolt
Grade 2
Grade 5
Grade 8
Grade BC
Pound-feet N-m Pound-feet N-m Pound-feet N-m Pound-feet N-m
1 x 8
350
475
901
1222
1272
1725
1114
1510
1 x 12 383 519 986 1337 1392 1887 -- --
1 x 14 393 533 1012 1372 1428 1936 -- --
1-1/8 x 7 496 672 1111 1506 1802 2443 1577 2138
1-1/8 x 12
556 754 1247 1691 2022 2741 -- --
1-1/4 x 7
700
949
1568
2126
2544
3449
2226
3018
1-1/4 x 12 774 1049 1737 2355 2816 3818 -- --
1-3/8 x 6 917 1243 2056 2788 3335 4522 2919 3958
1-3/8 x 12 1044 1415 2341 3174 3797 5148 -- --
1-1/2 x 6
1217 1650 2729 3700 4426 6001 3873 5251
1-1/2 x 12
1369
1856
3071
4164
4980
6752
--
--
Table 10: Torque Values if You Apply LocTite 277
Dimension
The Grade of the Bolt
Grade 2 Grade 5 Grade 8 Grade BC
Pound-feet
N-m
Pound-feet
N-m
Pound-feet
N-m
Pound-feet
N-m
1 x 8 325 441 837 1135 1181 1601 1034 1402
1 x 12 356 483 916 1242 1293 1753 -- --
1 x 14
365
495
939
1273
1326
1798
--
--
1-1/8 x 7
461 625 1032 1399 1674 2270 1464 1985
1-1/8 x 12
516
700
1158
1570
1877
2545
--
--
1-1/4 x 7 650 881 1456 1974 2362 3202 2067 2802
1-1/4 x 12 719 975 1613 2187 2615 3545 -- --
1-3/8 x 6 851 1154 1909 2588 3097 4199 2710 3674
1-3/8 x 12
970 1315 2174 2948 3526 4781 -- --
1-1/2 x 6
1130
1532
2534
3436
4110
5572
3597
4877
1-1/2 x 12 1271 1723 2852 3867 4624 6269 -- --
1.2.
Stainless Steel Fasteners
Table 11: Torque Values for Stainless Steel Fasteners 5/16-inch and Smaller
Dimension
316 Stainless 18-8 Stainless
18-8 Stainless with
Loctite 767
Pound-Inc
hes N-m
Pound-Inc
hes N-m
Pound-Inc
hes
N-m
1/4 x 20
79
9
76
9
45
5
1/4 x 28 100 11 94 11 56 6
5/16 x 18 138 16 132 15 79 9
5/16 x 24 148 17 142 16 85 10
