PELLERIN MILNOR CORPORATION
BIIFBM03 (Published) Book specs- Dates: 20090814 / 20090814 / 20100514 Lang: ENG01 Applic: MXA
Safety Placards and Locations—ISO
30022X8W, 36026X8W, 42026X7W, 42032X7W
• This document is for placards that agree with: ISO
• If the placard is removed or you cannot read it, replace the placard immediately.
• If the placard is aluminum, the mounting holes are on the machine. Use #8 self-tapping
screws. If the placard is vinyl, put the placard in the approximate location shown.
Figure 1: 30022X8W
General Views
Legend
A. Front view
B. Rear view
.
59
