13 Measurement, Comments and Body Mark

Operator’s Manual 13 - 5

3. Tap [Delete Word] or press <Clear> to complete the deletion.

Deleting a recently-added character, text or arrow

In comment status, press <Clear> to delete the latest added/modified comment unit.

Enter letters by pressing the alphanumeric key on the keyboard and use blank key to divide the

letters. Press the user-defined key for “Delete Word” to delete latest added/modified comment unit

and enter comment status.

Delete letters one by one

In comment editing status, tap <Back> to delete letters before cursor “|”.

In comment editing status, tap <Del> to delete letters after cursor “|”.

In comment status, enter letters by pressing the alphanumeric key on the keyboard. Press the user-

defined key for “Delete Word” to delete letters before cursor “|”.

Erase All Text

NOTE:

• When no item is selected, press <Clear> will clear all comments and all measurements

calipers.

• After powering off, the system will clear all comments on the image.

Press the user-defined key for “Delete Text” or long press <Clear> key to delete all the comments.

13.2.5 Setting the Start Position

Perform the following procedure:

1. Select <ABC> > [Comments] or press the user-defined key for “Annotation” to enter the

comment status.

2. Move the cursor to the target position, then press <Set Home> to set the start position of the

comment.

Tap <Home> on the touch screen; the cursor returns to the start position.

13.3 Body Mark

NOTE:

After powering off, the system will clear all comments on the image.

The Body Mark feature is used for indicating the exam position of the patient and transducer

position and orientation.

You can preset the system configured general body marks for each exam mode. The system

supports the import of user-defined body marks.

For products equipped with the trackpad, set user-defined keys for bodymark first, see “4.1.7 Key

Configuration”.

13.3.1 Adding Body Mark

Perform the following procedure:

1. Press or the user-defined key for “Body Mark” to enter the Body Mark status.

2. Tap the desired body mark on the touch screen directly.
