4 - 30 Operator’s Manual
4 Setup
– Select the required option from the Clip Capture drop-down list.
– Select the number of loops to acquire (per view in the selected phase) in the Loops list (for
non-continuous stages).
– Select the type: exercise or drug.
5. Click [OK] to save changes and quit.
Editing a Stress Echo Protocol
Perform the following procedure:
1. Click a user-defined protocol on the Select Protocol screen.
2. Edit the protocol as described in the create protocol.
Deleting a Stress Echo Protocol
Click an user-defined protocol on the Select Protocol screen, click [Delete Protocol].
4.6.2 Maintenance
Item Description
Acquire mode Set the type of ROI: manual ROI or full-screen.
Overlay Select the items to be labeled on each loop.
WMS score type Set the chamber segment division method.
QT-Time table To customize the length of systolic duration acquired for a specific heart
rate, it will store the clip duration. You can add and remove entries in
this table. You can also load the factory defaults.
Heart rate Enter the heart rate.
Syst. duration Enter the systolic duration.
Load factory To reset the QT time table.
