13 - 6 Operator’s Manual
13 Measurement, Comments and Body Mark
3. To adjust the probe position and orientation marker:
– Use the trackball/trackpad to place the probe marker at the correct position.
– Rotate <Angle> to adjust the mark’s direction.
– Tap [Save Probe] to save the current direction and position for the probe mark of the
current body mark.
4. Press <Set> to confirm the position and orientation of the probe marker and exit the body mark
mode.
13.3.2 Moving Body Marks
You can move the body mark graphics to any desired position within the image area.
NOTE:
In Dual B Mode, a Body Mark cannot be moved between the separate image windows.
Perform the following procedure:
1. Press <Cursor> and use the trackball/trackpad to move the cursor onto the body mark. The
cursor then becomes , indicating you can move the Body Mark graphic to a new position.
2. Press <Set> key to select the body mark.
3. Use the trackball/trackpad to move the Body Mark graphic to the desired position.
4. Press <Set> key to anchor and confirm the new graphic position.
13.3.3 Deleting Body Marks
TIP:
• Preset returning, switching the exam mode/patient/probe will clear the body marks.
• Set if body mark is erased when the image is unfrozen, see “4.1.4 Application”.
Perform the following procedure:
1. Press <Cursor> and use the trackball/trackpad to move the cursor onto the body mark. The
cursor then becomes .
2. Press <Clear> to delete the body mark.
