4 - 26 Operator’s Manual
4 Setup
1. Select the [Report] on the [Measure] page.
2. Select a report template from the list.
3. Click [Default].
4. Click [OK] to confirm.
4.4 Comment Preset
You can preset the custom comments library for current exam mode. The comments in the library
are provided by the system or user-defined ones.
4.4.1 Comment Configure
Add a user-defined item
Directly enter user-defined comment texts: posit the cursor in the field box above [Add Comment],
enter the text comment through the soft keyboard, and then click [Add Comment]. Then the
directly-entered comment will be added to the Selected Items.
Select available items
Perform the following procedure:
1. Select available items:
a. Select a comment library in the drop-down list below “Application”.
b. Select a comment type in the drop-down list below “Type”.
All items will be displayed below “Available Items”.
2. Click [>], [>>], [<] and [<<] to add the item in Available Items on the left into Selected Items
on the right.
You can only delete the user-defined items rather than the items in the system library. After a user-
defined item is deleted, it will not be available.
Change position of the selected items
Select an item on the right side box and click [Up], [Down], [Left] or [Right] button to change the
position of the item.
4.4.2 Comment Group Define
Add user-defined group
Enter user-defined group name in the name text box below [Lists Name] through the soft keyboard,
click [Add Group]. The entered group name will be added to the Group Lists.
Add comment items to the user-defined group
Perform the following procedure:
1. Select a user-defined comment group from the “Group Lists”.
2. Do one of following to add comment items:
– Select a comment library in the drop-down list below “Application”: Select a comment
item, click [>] to add it into Selected Items on the right; click [>>] to add all items into
Selected Items on the right directly
