4 Setup
Operator’s Manual 4 - 11
– Send image to USB disk
– Send image to iStorage
– Send image to local printer
• Retrospective/prospective saving cine:
– Send cine to DICOM storage
– Send cine to USB disk
– Send cine to iStorage
Setting method (taking “Save Image” as an example, add the auxiliary functions “Send Image to
DICOM Storage” and “Send Image to USB disk”):
1. Select a key in the Key Function field on the left side and select “Save Image” in the Output
page of Function field on the right side.
2. Click [Add] in the middle part of the screen, then there will be “Function 2: NULL” under the
key function in the Key Function Field on the left side, and at the same time, “Output” column
on the right side will show the available auxiliary functions for current key. Select “Send
Image to DICOM Storage” in the “Output” column on the right side. Then the Function 2 on
the left side turns into “Send Image to DICOM Storage”.
3. Click [Add] again, then there will be “Function 3: NULL” under the key function in the Key
Function Field on the left side. Select “Send Image to USB disk” in the “Output” column on
the right side. Then the Function 3 on the left side turns into “Send Image to USB disk”.
4. Click [OK] to confirm.
5. Scan and freeze the image
6. Press the user-defined key, then the system will perform three steps:
a. Save the image to the local hard disk.
b. Send image to DICOM Storage server.
c. Send the image to USB disk.
Repeat step 3 will continue adding auxiliary functions; you can add 6 functions at most.
4.1.8 Gesture
The gesture setting is the same with the settings of other keys, see “4.1.7 Key Configuration”.
