Mindray Nuewa R9 Elite User Manual

Field Replaceable Unit 8-29
No.
Order Number
Part Name
Qty.
Remark
G7-1
115-036196-00 Power-in FRU assembly(220V) 1 Support AC 220V
115-036197-00 Power-in FRU assembly(110V) 1 Support AC 110V
G7-2 115-052886-00
24V Power Board(FRU) 1
G7-3
115-052879-00
AC Power Module(UR/FRU) 1
G7-4 043-003480-00 base filter 6
8.2.8 Cable (H0)
No.
Order Number
Part Name
Qty.
Remark
H1 0020-20-12524 Cable,power(EU) 1
power cord from customer site power socket -
power in assembly
H2 009-004577-00 Auxiliary power output cable 2 power cord from power in assembly to Peripheral
H3 009-008375-00 Display wires (HDMI) 1
The cables from display to LCD signal connector
board, including power and signal two cables.
Suit for big HDMI port display.
H4 009-008376-00 Cable Assembly of main unit (HDMI) 1
The cables from LCD signal connector board
display to display, including power and signal
two cables.
H5 009-004554-01 touch panel power cable 1 control panel,J2 - touch screen
H6 009-004556-00 usb cable of touch panel 1 Control panel,J31- touch screen
H7 009-004562-00 HEATER PWR CABLE 2 Control panel,J38/J39-Gel warmer
H8 009-004565-00 Encoder signal connecting wires 1 Control panel,J45-single encoder board
H9 009-004566-00 multifunctional Encoder signal wires 2
Control panel,J45-multi-function/Universal
encoder board PCBA
