Mindray Nuewa R9 Elite User Manual

2-10 Specifications
Key
Function
F11 Biopsy
Display/hide the guide line.
F12 Physio Enter Physio mode.
For user-defined keys, please refer to the operator’s manual [Basic Volume].
2.1.3 Peripherals Supported
Type
Model
Graph/text printer HP OFFICEJET PRO 8100 (the printer driver requires manual installation.)
Black/white video
printer (digital)
MITSUBISHI P95DW-N
Black/white video
printer (analog)
SONY UP-X898MD
Digital color video
printer
SONY UP-D25MD
Barcode reader
SYMBOL LS2208 (1D), SYMBOL DS4308 (2D)
Footswitch USB port: 971-SWNOM (2-pedal, 3-pedal), FS-81-SP-2 (1-pedal)
Note: the printer driver is preinstalled in the system. Please install other printer drivers for other
types of the printers.
2.2 Specifications
2.2.1 Dimensions & Weight
The appearance (the monitor and the control panel stay at the minimum position.)
Lifting support arm: Depth: 945±10 mm; width: 545±10 mm (main unit)/510±10 mm (control panel);
height: 1360±10 mm (with the display vertical).
Dual-wing floating arm: Depth: 945±10 mm; width: 545±10 mm (main unit)/510±10 mm (control
panel); height: 1390±10 mm (with the display vertical).
Weight (net weight, standard configured but not including the probe weight): less than 134.4 Kg.
2.2.2 Electrical Specifications
2.2.2.1 AC Input
Voltage
220-240～, 100-127V～
Frequency
50/60Hz
Power consumption
1000VA

Mindray Nuewa R9 Elite Specifications

General

Brand	Mindray
Model	Nuewa R9 Elite
Category	Diagnostic Equipment
Language	English
