– 55 –
Flap Control Setting
Motion range (upper and lower limit positions) of the fl ap at each air outlet can be set at a desired
range individually.
Caution
When changing contents of the individual fl ap control, stop the air conditioner.
1. Press FLAP CONTROL SETTING button on the OPERATOR MENU.
2
4
3
2. Press SELECT UNIT button. Select Group and Unit by pressing group name and unit
number, and press the OK button.
Model of unit is being asked. Please wait for a while.
If you do not want to make the setting, press the cancel button.
3. Select the upper and lower limit positions of each fl ap from 1 to 6 for the range of fl ap
motion.
4. Press the SET button.
When changing the range of fl ap motion for other unit, repeat 2. to 4..
To Next Page
