α
2 Simple Application Controllers
AL2-GSM-CAB 8
ENG-38
8.2 Installation
When installing AL2-GSM-CAB refer to Figure 8.4.
Caution
• Persons trained in the local and national electrical standards must install or remove the
AL2-GSM-CAB.
• Turn off the power supply when installing or removing the AL2-GSM-CAB.
• Put the cover back on after either installing or removing the AL2-GSM-CAB.
• Under no circumstances will Mitsubishi Electric be liable or responsible for any
consequential damage that may arise as a result of the installation or use of this
equipment.
• Do not pull on the cord, otherwise the cable may be damaged.
• When communicating to
α
2 series via GSM modem, the power supply for both units
must be turned ON at the same time. If they are not started up at same time, the
α
2
series will not communicate via GSM modem.
• Disconnect all terminals from the power supply before removing the cover.
To Next Page
