PARAMETERS
132
4.2.36 Output (remote input) function selection (Pr. 190 to Pr. 192)
Pr. 190 "
(
RX2
)
function selection"
Pr. 191 "
(
RX6
)
function selection"
Pr. 192 "A, B, C terminal
(
RX7
)
function selection"
You can change the functions of the contact output terminals (remote input).
Parameter
Number
Terminal
(Remote Input)
Symbol
Factory
Setting
Factory-Set Terminal
Function
Setting
Range
190 (RX2) 0 Inverter running 0 to 99
191 (RX6) 4 Frequency detection 0 to 99
192 ABC(RX7) 99 Alarm output 0 to 99
<Setting>
Refer to the following table and set the parameters:
Setting
Signal
Name
Function Operation
Related
Parameters
0 RUN Inverter running
Output during operation when
the inverter output frequency
rises to or above the starting
frequency.

1 SU Up to frequency
Refer to Pr. 41 "up-to-frequency
sensitivity". (Note 1)
Pr. 41
3 OL Overload alarm
Output while stall prevention
function is activated.
Pr. 22, Pr. 23,
Pr. 66
4FU
Output frequency
detection
Refer to Pr. 42, Pr. 43 (output
frequency detection).
Pr. 42, Pr. 43
11 RY
Inverter operation
ready
Output when the inverter is
ready to be started by switching
the start signal on.

12 Y12
Output current
detection
Refer to Pr. 150 and Pr. 151
(output current detection).
Pr. 150,
Pr. 151
13 Y13
Zero current
detection
Refer to Pr. 152 and Pr. 153
(zero current detection).
Pr. 152,
Pr. 153
98 LF Minor fault output
Output when a minor fault
occurs.
Pr. 244
99 ABC Alarm output
Output when the inverter's
protective function is activated to
stop the output (major fault).

Note:1. The same function may be set to more than one terminal (remote input).
2. Pr. 190 to Pr. 192 do not function if the values set are other than the above.
