4.1 Parameter List
PARAMETERS
68
4 PARAMETERS
4.1 Parameter List
4.1.1 Parameter list
Func-
tion
Para-
meter
Number
Name
Setting
Range
Minimum
Setting
Increments
Factory
Setting
Refer
To:
Custo-
mer
setting
0 Torque boost (Note 1) 0 to 30% 0.1% 6% 76
1 Maximum frequency 0 to 120Hz 0.01Hz 120Hz 77
2 Minimum frequency 0 to 120Hz 0.01Hz 0Hz 77
3
Base frequency
(Note 1)
0 to 400Hz 0.01Hz 60Hz 78
4
Multi-speed setting
(high speed)
0 to 400Hz 0.01Hz 60Hz 79
5
Multi-speed setting
(middle speed)
0 to 400Hz 0.01Hz 30Hz 79
6
Multi-speed setting
(low speed)
0 to 400Hz 0.01Hz 10Hz 79
7 Acceleration time
0 to 3600 s/
0 to 360 s
0.1 s/
0.01 s
5 s/10s
(Note 2)
80
8 Deceleration time
0 to 3600 s/
0 to 360 s
0.1 s/
0.01 s
5 s/10s
(Note 2)
80
Basic functions
9
Electronic thermal O/L
relay
0 to 500A 0.01A
Rated
output
current
(Note 3)
82
10
DC injection brake
operation frequency
0 to 120Hz 0.01Hz 3Hz 83
11
DC injection brake
operation time
0 to 10 s 0.1 s 0.5 s 83
12
DC injection brake
voltage
0 to 30% 0.1% 6% 83
13 Starting frequency 0 to 60Hz 0.01Hz 0.5Hz 84
14
Load pattern selection
(Note 1)
0 to 3 1 0 84
18
High-speed maximum
frequency
120 to
400Hz
0.01Hz 120Hz 77
19
Base frequency
voltage (Note 1)
0 to 1000V,
8888, 9999
0.1V 9999 78
20
Acceleration/
deceleration
reference frequency
1 to 400Hz 0.01Hz 60Hz 80
21
Acceleration/
deceleration
time increments
0, 1 1 0 80
22
Stall prevention
operation level
0 to 200% 0.1% 150% 86
Standard operation functions
23
Stall prevention
operation level
compensation factor at
double speed (Note 6)
0 to 200%,
9999
0.1% 9999 86
