3.3.3 Instruction Codes
Item
Code
Number
Description
Operation mode read 007B
H
0000
H
: CC-Link operation
0002
H
: PU operation
Operation mode write 00FB
H
0000
H
: CC-Link operation
0002
H
: PU operation
Alarm history No. 1, No. 2 read 0074
H
Reads the most recent No. 1 and 2 alarms.
Alarm history No. 3, No. 4 read 0075
H
Reads the most recent No. 3 and 4 alarms.
Alarm history No. 5, No. 6 read 0076
H
Reads the most recent No. 5 and 6 alarms.
Alarm history No. 7, No. 8 read 0077
H
Reads the most recent No. 7 and 8 alarms.
Set frequency (RAM) read 006D
H
Reads the set frequency (RAM). (Note)
Set frequency (E
2
PROM) read 006E
H
Reads the set frequency (E
2
PROM). (Note)
Set frequency (RAM) write 00ED
H
Writes the set frequency to RAM. (Note)
Set frequency (E
2
PROM) write 00EE
H
Writes the set frequency to E
2
PROM. (Note)
Parameter read
0000
H
to
006C
H
Parameter write
0080
H
to
00EC
H
Refer to the parameter data code list (page 171) and perform read/write
as required.
It should be noted that some parameter values cannot be read nor
written.
Batch alarm definition clear 00F4
H
9696
H
: Batch-clears the alarm history.
Parameter clear 00FC
H
9696
H
: Parameter clear (Parameters other than calibration values are
returned to factory settings)
9966
H
: All clear
Inverter reset 00FD
H
9696
H
: Resets the inverter.
Read
007F
H
Link parameter expansion
setting
Write
00FF
H
Changes the 0000
H
to 006C
H
and 0080
H
to 00EC
H
parameter values.
0000
H
: Pr. 0 to Pr. 99
0001
H
: Pr. 100 to Pr. 159
0002
H
: Pr. 160 to Pr. 199, Pr. 232 to Pr. 250
0005
H
: Pr. 500 to Pr. 502
0009
H
: Pr. 990, Pr. 991
Note: Setting can be made from the remote registers.
