4.1.2 List of parameters classified by purpose of use
Set the parameters according to the operating conditions. The following list indicates
purpose of use and corresponding parameters.
Parameter Numbers
Purpose of Use
Parameter numbers which must be set
Operation mode selection Pr. 79
Acceleration/deceleration time/pattern adjustment Pr. 7, Pr. 8, Pr. 20, Pr. 21, Pr. 29
Selection of output characteristics optimum for
load characteristics
Pr. 14
Output frequency restriction (limit) Pr. 1, Pr. 2, Pr. 18
Operation over 60Hz Pr. 1, Pr. 18
Motor output torque adjustment Pr. 0, Pr. 80
Brake operation adjustment Pr. 10, Pr. 11, Pr. 12
Multi-speed operation
Pr. 4, Pr. 5, Pr. 6, Pr. 24, Pr. 25, Pr. 26, Pr. 27, Pr. 232,
Pr. 234, Pr. 235, Pr. 236, Pr. 237, Pr. 238, Pr. 239
Frequency jump operation Pr. 31, Pr. 32, Pr. 33, Pr. 34, Pr. 35, Pr.36
Automatic restart operation after instantaneous
power failure
Pr. 57, Pr. 58
Optimum acceleration/deceleration within
continuous rated range
Pr. 60
Slip compensation setting Pr. 245 to Pr. 247
Related to operation
Output stop method selection Pr. 250
General-purpose magnetic flux vector control
operation
Pr. 80
Electromagnetic brake operation timing Pr. 42
Offline auto tuning setting Pr. 82 to Pr. 84, Pr. 90, Pr. 96
Sub-motor operation
Pr. 0, Pr. 3, Pr. 7, Pr. 8, Pr. 9, Pr. 44, Pr. 45, Pr. 46, Pr. 47,
Pr. 48
Regenerative function selection Pr. 30, Pr. 70
Operation in communication with personal
computer
Pr. 117 to Pr. 124
Related to application
operation
Noise reduction Pr. 72, Pr. 240
Display of speed, etc. Pr. 37, Pr. 52
Related to
monitoring
Clearing of inverter's actual operation time Pr. 171
Function write prevention Pr. 77
Reverse rotation prevention Pr. 78
Parameter grouping Pr. 160, Pr. 173 to Pr. 176
Current detection Pr. 150 to Pr. 153
Related to
false operation
prevention
Motor stall prevention Pr. 22, Pr. 23, Pr. 66, Pr. 156
Input terminal function assignment Pr. 180 to , Pr.183
Output terminal function assignment Pr. 190 to Pr. 192
Increased cooling fan life Pr. 244
Motor protection from overheat Pr. 9
Automatic restart operation at alarm stop Pr. 65, Pr. 67, Pr. 68, Pr. 69
Start-time ground fault overcurrent protection
setting
Pr. 249
Others
Inverter reset selection Pr. 75
