Mitsubishi Q02HCPU User Manual

6
FUNCTIONS
6.7 Q Series Compatible Module Input Response Time Selection (I/O Response Time)
6 - 39
1
Overview
2
Performance Specification
3
Sequence Program Configuration and Execution Conditions
4
I/O Nunber Assignment
5
Memories and Files Handled by CPU Module
6
Functions
7
Communication using built-in Ethernet ports of CPU module
8
Communication with Intelligent Function Module
(3) Precautions
(a) Restrictions on GX Developer version and the relevant modules
When changing the input response time of the high-speed input module or
interrupt module, use GX Developer version indicated in Table6.15.
If GX Developer version earlier than the version indicated in Table6.15 is used,
the module will operate with the default value of the input response time.
(b) When input response time is shortened
If the input response time is set shorter, an input module becomes susceptible to
noise.
Set the desired input response time by taking into consideration the operating
environment of an input module in use.
(c) When AnS/A series corresponding input module is used
Note6.6
Note6
No change can be made to the input response time of an AnS/A Series
corresponding input module.
When the input response speed is set to the slot of the AnS/A series compatible
input module or interrupt module, the settings will be ignored.
(d) Timing when settings are ensured
The input response speed setting is valid in the following cases.
• When the PLC is powered OFF and then ON
• When the CPU module's RESET switch is set to neutral position
Table6.15 Applicable GX Developer version
Module Applicable GX Developer version
High-speed input module GX Developer Version 5 (SW5D5C-GPPW-E) or later
Interrupt module GX Developer Version 6 (SW6D5C-GPPW-E) or later
Note6
Universal
UD
Note6.6
Basic
Process
Redundant
Note6.6
Note6.6
Note6.6
The Basic model QCPU, Process CPU, Redundant CPU and Universal model QCPU do not
support the AnS/A series corresponding modules.
Basic
Process Redundant
Universal
UD
Note6.6
Note6.6
Note6.6
Note6.6
