9.3 Network Parameters
9
PARAMETERS
(1) CC-Link IE controller network setting
Note9.7
The network parameter of the CC-Link IE controller network is set.
* 1 : Can be set only when the Redundant CPU is used.
Note6
Figure 9.27 Number of modules on Ethernet/CC IE/MELSECNET.
(When CC-Link IE controller network is set)
Table9.31 CC-Link IE controller network setting list
Item Parameter No. Description Setting range Default value Reference
Number of modules on
CC-Link IE controller
network
A000
H
Sets the network parameter of
the CC-Link IE controller
network.
Refer to the manual for the Q
corresponding CC-Link IE
controller network
---- ----
Starting I/O No.
ANM0
H
Network No.
Total stations
Station No.
Group No. 0AmnH
Mode ANM0H
Refresh parameters ANM1H
Setup Common
parameters
ANM2
H
Station inherent
parameters
ANM3
H
Group setting
*1
D004H
Redundant settings
*1
DA**H
Interlink transmission
parameters
A002
H
Routing parameters A003H
Note6
Basic
Note9.7
The Basic model QCPU cannot specify "CC IE Control (Control station)".
Basic
Note9.7
