10
DEVICE EXPLANATION
10 - 1
10.1 Device List
CHAPTER10 DEVICE EXPLANATION
This chapter describes all devices that can be used in the CPU module.
10.1 Device List
The names and data ranges of devices which can be used in the CPU module are shown
in Table10.1 and Table10.2.
(1) Basic model QCPU
(Continued on next page)
Table10.1 Device List
Class Type Device Name
Default Values Parameter
Designated
Setting Range
Reference
Section
Number of
Points
Range Used
Internal
user
devices
Bit
devices
Input 2048 X0 to 7FF Hexadecimal
Changeable
within
16.4k words.
*2
Section 10.2.1
Output 2048 Y0 to 7FF Hexadecimal
Section 10.2.2
Internal relay 8192 M0 to 8191 Decimal
Section 10.2.3
Latch relay 2048 L0 to 2047 Decimal
Section 10.2.4
Annunciator 1024 F0 to 1023 Decimal
Section 10.2.5
Edge relay 1024 V0 to 1023 Decimal
Section 10.2.6
Step relay 2048 S0 to 127/block Decimal
Section 10.2.9
Link relay 2048 B0 to 7FF Hexadecimal
Section 10.2.7
Special link relay 1024 SB0 to 3FF Hexadecimal
Section 10.2.8
Word
devices
Timer
*1
512 T0 to 511 Decimal
Section 10.2.10
Retentive timer
*1
0 (ST0 to 511) Decimal
Counter
*1
512 C0 to 511 Decimal
Section 10.2.11
Data register 11136 D0 to 11135 Decimal
Section 10.2.12
Link register 2048 W0 to 7FF Hexadecimal
Section 10.2.13
Link special register 1024 SW0 to 3FF Hexadecimal
Section 10.2.14
Internal
system
devices
Bit
devices
Function input 16 FX0 to F Hexadecimal
Unchangeable
Section 10.3.1
Function output 16 FY0 to F Hexadecimal
Section 10.3.1
Special relay 1024 SM0 to 1023 Decimal
Section 10.3.2
Word
devices
Function register 5 FD0 to 4 Decimal
Section 10.3.1
Special register 1024 SD0 to 1023 Decimal
Section 10.3.3
Link direct
devices
Bit
device
Link input 8192 Jn\X0 to 1FFF Hexadecimal
Unchangeable
Section 10.4
Link output 8192 Jn\Y0 to 1FFF Hexadecimal
Link relay 16384 Jn\B0 to 3FFF Hexadecimal
Link special relay 512 Jn\SB0 to 1FF Hexadecimal
Word
device
Link register 16384 Jn\W0 to 3FFF Hexadecimal
Link special register 512 Jn\SW0 to 1FF Hexadecimal
Intelligent
function
module
device
Word
device
Intelligent function
module device
65536
Un\G0 to
65535
*3
Decimal Unchangeable
Section 10.5
Index
register
Word
device
Index register 10 Z0 to 9 Decimal Unchangeable
Section 10.6
