Mitsubishi Q02HCPU User Manual

1
OVERVIEW
1.3 Devices and Instructions Convenient for Programming
1 - 32
1
Overview
2
Performance Specification
3
Sequence Program Configuration and Execution Conditions
4
I/O Nunber Assignment
5
Memories and Files Handled by CPU Module
6
Functions
7
Communication using built-in Ethernet ports of CPU module
8
Communication with Intelligent Function Module
(e) Direct access to link devices
Access can be made to the link device (LX, LY, LB, LW, SB, or SW) of the CC-Link
IE controller network module and the MELSECNET/H network module without the
refresh setting.( Section 10.4)
Figure 1.24 Direct access to link devices
M0
J5\W12
Direct readout of the No.5 network module's
"LW12" link register
Link register
designation
Network No.
designation
D0
J5\W12+P
Network No.5
QJ71LP21-25
Input module Input module
Q68AD Q68AD Q62DA
Output module Output module
16
points
16
points
16
points
16
points
16
points
16
points
16
points
012 45673

Mitsubishi Q02HCPU Specifications

General

Power Supply	24 VDC
Number of Connectable I/O Modules	Up to 64 modules
Operating Temperature	0 to 55 °C
CPU	Q02H
Number of I/O Points	4096
Communication	Ethernet, Serial
Operating Humidity	10 to 90% RH (non-condensing)
Type	MELSEC-Q Series High Performance Model Q02HCPU
