UHF Band 2 Circuit Board/Schematic Diagrams and Parts List (PCB 8486686Z02) 9-231
C411 2113743M24 100000pF
C414 2113743M24 100000pF
C415 2185895Z01 0.01uF
C416 2113928N01 0.1uF
C419 NOT PLACED -
C420 2113743L41 10000pF
C421 2113928N01 0.1uF
C422 2113743M24 100000pF
C423 2113743N50 100pF
C424 2311049A59 10uF
C425 2113743M24 100000pF
C426 2113743N50 100pF
C427 2113743N50 100pF
C428 2113743M24 100000pF
C429 2113743M24 100000pF
C430 2113928N01 0.1uF
C431 2113743N50 100pF
C432 NOT PLACED -
C433 2113743L41 10000pF
C434 2113928N01 0.1uF
C435 2113743M24 100000pF
C436 2113743N34 22pF
C437 2113743N34 22pF
C440 2113743G26 4.7uF
C441 2113743N50 100pF
C442 2113743E20 0.1uF
C443 2113928N01 0.1uF
C444 2113743N50 100pF
C445 2113743N50 100pF
C447 2113743M08 22000pF
C448 2113928N01 0.1uF
C449 2113743N50 100pF
C450 NOT PLACED -
C451 2113743M08 22000pF
C452 2113743B29 1uF
C453 2113743N50 100pF
C456 2113743N50 100pF
C458 2113743N50 100pF
C459 2113743N50 100pF
C463 2113743N50 100pF
C466 2113743N50 100pF
C467 2113928N01 0.1uF
C471 2113743N50 100pF
C472 2113743L09 470pF
C473 2113743L09 470pF
C475 2113743H14 10uF
C476 2113928D08 10uF
C479 2113928N01 0.1uF
C480 2113928D08 10uF
C481 2113928N01 0.1uF
C482 2113928N01 0.1uF
Circuit
Ref
Motorola
Part No.
Description
C490 2113743N50 100pF
C491 2113743N50 100pF
C492 2113743N50 100pF
C493 2113743N50 100pF
C494 2113743N50 100pF
C495 2113743N50 100pF
C496 2113743N50 100pF
C497 2113743N50 100pF
C498 NOT PLACED -
C502 2311049A05 0.47uF
C503 2113743N50 100pF
C505 2113743N50 100pF
C511 2113743N50 100pF
C512 2113743N50 100pF
C513 2113743N50 100pF
C514 2113743N50 100pF
C520 2113743L41 10000pF
C521 2113743L41 10000pF
C522 2113743L41 10000pF
C523 2113743L41 10000pF
C524 2113743N50 100pF
C525 2113743N50 100pF
C526 2113743N50 100pF
C527 2113743N50 100pF
C528 2113743N50 100pF
C529 2113743N50 100pF
CR101 4880973Z02 Pin Diode
CR102 4802245J41 Pin Diode
CR103 4802245J41 Pin Diode
CR105 5185963A15 Temperature Sensor
CR160 NOT PLACED -
CR201 4802233J09 Triple Diode
CR203 4862824C03 Varactor
CR241 4805649Q13 Varactor
CR242 4862824C01 Varactor
CR243 4862824C01 Varactor
CR251 4802245J22 Varactor
CR301 4862824C01 Varactor
CR302 4862824C01 Varactor
CR303 4880154K03 Dual Schottky Diode
CR304 4862824C01 Varactor
CR305 4862824C01 Varactor
CR306 4802245J42 Ring Quad Diode
CR311 4813825A19 Diode Schottky
CR312 4802245J97 Switch Diode
CR313 4802245J97 Switch Diode
CR411 4802245J62 Diode Schottky
CR412 4802245J62 Diode Schottky
CR413 4802245J62 Diode Schottky
CR440 4813833C02 Dual Common Cathode Diode
CR501 4880107R01 Rectifier
Circuit
Ref
Motorola
Part No.
Description
CR503 4805729G49 Red/Yellow LED
E101 2484657R01 Ferrite Bead
E400 2480640Z01 Ferrite Bead
E401 2480640Z01 Ferrite Bead
E402 2480640Z01 Ferrite Bead
E403 2480640Z01 Ferrite Bead
E404 2480640Z01 Ferrite Bead
E405 2480640Z01 Ferrite Bead
E406 2480640Z01 Ferrite Bead
E407 2480640Z01 Ferrite Bead
E408 2480640Z01 Ferrite Bead
E409 2480640Z01 Ferrite Bead
F501 6580542Z01 Fuse 3A
FL201 4805875Z04 16.8 MHz Xtal Filter
FL301 9180022M11 Xtal Filter 44.85MHz
FL302 9180468V05 455kHz 4-pole ceramic filter
FL303 9180469V05 455kHz 6-pole ceramic filter
FL304 9180469V03 455kHz 6-pole ceramic filter
FL401 4870368G02 Real Time Clock Xtal Oscillator
38.4kHz (not placed in
PRO5450)
H101 2680499Z01 Heat Spreader
J101 0985613Z01 RF Jack
J102 0280519Z02 Antenna Nut
J400 0905505Y04 40-Pin Connector
J403 0905505Y02 20-Pin Connector
L101 2460591B28 13.37nH
L102 2460591B28 13.37nH
L104 2460591B48 15.22 nH
L105 2462587N22 390nH
L106 2460591A19 8.71nH
L107 2479990G01 33.47nH
L108 2479990A01 4.22nH
L112 2462587N42 12nH
L113 2413926H09 5.6nH
L114 2462587N42 12nH
L115 2462587N22 390nH
L116 2479990C02 16.28nH
L117 2409154M17 22nH
L160 2413926H14 15nH
L201 2462587Q20 2200nH
L202 2462587Q20 2200nH
L203 2462587Q20 2200nH
L232 2462587P25 12000nH
L241 2462587V41 390nH
L242 2462587V26 22nH
L243 2485776Z02 Multi-layered Teflon resonator,
Rx
L251 2462587V41 390nH
L253 2460593C03 Multi-layered Teflon resonator,
Tx
Circuit
Ref
Motorola
Part No.
Description
L261 2462587V29 39nH
L271 2462587V27 27nH
L273 2462587V32 68nH
L281 2462587V41 390nH
L282 2462587V41 390nH
L301 2479990B01 11.03n H
L302 2479990B01 11.03nH
L303 2462587V26 22nH
L304 2462587V37 180nH
L305 2462587V23 12nH
L306 2479990B01 11.03nH
L307 2479990B01 11.03n H
L309 2479990C02 16.28nH
L310 2462587V36 150nH
L311 2413926K32 560nH
L321 2462587V37 180nH
L325 2462587N68 1000nH
L330 2413926K33 680nH
L332 2413923A25 1200nH
L400 2462587Q42 390nH
L401 2462587Q42 390nH
L410 2462587Q42 390nH
L411 2462587Q42 390nH
L505 2462587Q42 390nH
P100 3905643V01 Ground Contact Finger
PB501 4086470Z01 Tactile Switch
PB502 4086470Z01 Tactile Switch
PB503 4086470Z01 Tactile Switch
PB504 4086470Z01 Tactile Switch
PB505 4086470Z01 Tactile Switch
Q110 4813828A09 RF PA
Q111 4809939C05 Dual NPN/PNP Transistor
Q210 4809939C05 Dual NPN/PNP Transistor
Q241 4805218N63 RF NPN Transistor
Q260 4809939C05 Dual NPN/PNP Transistor
Q261 4809939C05 Dual NPN/PNP Transistor
Q301 4802245J44 NPN Transistor
Q302 4802197J95 NPN Transistor
Q310 4802245J44 NPN Transistor
Q320 4813824A10 RF NPN transistor
Q400 4809579E18 MOSFET P-Channel
Q403 4813824A17 PNP Transistor
Q405 4802245J54 Dual NPN Transistor
Q410 4802245J54 Dual NPN Transistor
Q416 4809579E18 MOSFET P-Channel (not
placed in PRO5450)
Q417 4809939C05 DUAL NPN/PNP Transistor
Q502 5180159R01 Dual NPN Transistor
Q505 4880214G02 NPN Transistor
R101 0662057A34 240
R102 0680539Z01 0.1
Circuit
Ref
Motorola
Part No.
Description
