8-4 Maintenance: Recommended Test Tools
7. Once complete, turn off the heat, raise the heat-focus head and wait approximately one
minute for the part to cool.
8. Remove the circuit board and inspect the repair. No cleaning should be necessary.
8.6 Recommended Test Tools
Table 8-1 lists the recommended tools used for maintaining this family of radios. These tools are also
available from Motorola.
Table 8-1. Recommended Test Tools
Motorola Part
Number
Description Application
RSX4043 Torx Driver Tighten and remove chassis screws.
6680387A70 T-6 Torx Bit Removable Torx driver bit.
R1453A Digital readout solder station Digitally controlled soldering iron.
0180386A78 Illuminated magnifying glass
with lens attachment.
0180386A82
6684253C72
6680384A98
1010041A86
1080303E45
Anti-static grounding kit
Straight prober
Brush
Solder (RMA type),
63/37, 0.5mm diameter
1 lb. spool
SMD tool kit (included with
R1319A)
Used during all radio assembly and disassembly
procedures.
R1319A (110V)
or R1321A(220V)
ChipMaster Surface Mount
Rework Station
Removal and assembly of surface-mounted
integrated circuits and shields includes 5 nozzles.
R1364A Digital Heated Tweezer
System
Chip component removal.
R1427A Board Preheater Reduces heatsink on multi level boards.
8880309B53 Rework Equipment Catalog Contains application notes, procedures and technical
rework equipment.
