Motorola HT Series User Manual

VHF Circuit Board/Schematic Diagrams and Parts List 9-387
VHF (136-174 MHz) 9000 Series Radio Parts
List
Circuit
Ref
Motorola Part
No.
Description
B501 0986237A02 Battery Contact Module
B503 3980502Z01 Backup battery B+
B504 3980501Z01 Backup battery B-
C3200 2113743N31 16pF
C3203 2113743N50 100pF
C3204 2113743L41 0.01uF
C3205 2113928N01 0.1uF
C3206 2113743L41 0.01uF
C3207 2113743N10 2.2pF
C3209 2311049A07 1uF
C3210 2113743L17 1000pF
C3211 2311049A56 4.7uF
C3212 2311049A07 1uF
C3213 2311049A56 4.7uF
C3214 2113928N01 0.1uF
C3215 2113743N26 10pF
C3218 2311049A56 4.7uF
C3219 2113928N01 0.1uF
C3220 2113743N26 10pF
C3221 2113743L41 0.01uF
C3222 2113928N01 0.1uF
C3223 2113928N01 0.1uF
C3224 2113928N01 0.1uF
C3225 2113928N01 0.1uF
C3226 2113928N01 0.1uF
C3227 2113743L41 0.01uF
C3228 2113743L41 0.01uF
C3229 2113743N50 100pF
C3230 2113740F51 100pF
C3231 2180478Z20 1uF
C3232 2180478Z20 1uF
C3233 2180478Z20 1uF
C3234 2180478Z20 1uF
C3235 2113743A23 0.220uF
C3238 2113743A24 .0.330uF
C3239 2113743E07 0.022uF
C3240 2113743A23 0.220uF
C3241 2113743L19 1200pF
C3242 2109720D14 0.1uF
C3243 2113743E07 0.022uF
C3244 2113743L41 0.01uF
C3270 2113743E07 0.022uF
C3271 2113743L05 330pF
C3272 2113743N18 4.7pF
C3273 2113743N26 10.0pF
C3274 2113743N38 33.0pF
C3275 2113743N44 56.0pF
C3276 2113743N42 47.0pF
C3277 2113743N48 82.0pF
C3278 2113743E07 0.022uF
C3279 2311049A40 2.2uF
C3280 2113743L41 0.01uF
C3301 2113743N20 5.6pF
C3302 2113743N54 150pF
C3303 2113743N30 15.0pF
C3304 2113743N54 150pF
C3306 2113928N01 0.1uF
C3307 2113743N50 100pF
C3308 2113743L05 330pF
C3309 2113928N01 0.1uF
C3311 2113743N54 150pF
C3312 2113743N31 16.0pF
C3313 2113743N54 150pF
C3315 2113743N26 10.0pF
C3316 2113743N14 3.3pF
C3317 2113743N40 39pF
C3318 2113743M08 0.022uF
C3320 2113743N48 82pF
C3321 2113743L05 330pF
C3322 2113743N50 100pF
C3323 2113743N50 100pF
C3324 2113743N38 33pF
C3325 2113743L17 1000pF
C3327 2113743L05 330pF
C3329 2113743L05 330pF
C3330 2113743N50 100pF
C3331 2113743N50 100pF
C3332 2113743N40 39pF
C3334 2113743N33 20pF
C3335 2113743N34 22pF
C3336 2311049A18 10uF
C3337 2113743M08 0.022pF
C3338 2113743L09 470pF
C3339 2113743N26 10pF
C3501 2113743L05 330pF
C3502 2113743N38 33pF
C3503 2113743N38 33pF
C3504 2113743M08 0.022pF
C3505 2113743N38 33pF
C3508 2113743M08 0.022pF
C3509 2113743L05 330pF
C3512 2113740F43 47pF
C3513 2113740F38 30pF
C3514 2113740F67 470pF
C3515 2113743L29 3300pF
C3516 2311049A08 1uF
C3517 2113740F51 100pF
C3518 2113740F63 330pF
C3519 2113740F35 22pF
C3521 2111078B51 220pF
C3523 2111078B44 120pF
C3524 2113740F33 18pF
C3525 2113740F27 10pF
C3526 2113743M08 0.022pF
C3528 2113740F26 9.1pF
C3531 2113740F34 20pF
C3532 2113740F47 68pF
C3533 2113740F24 7.5pF
C3534 2113740F19 4.7pF
C3535 2113740F37 27
Circuit
Ref
Motorola Part
No.
Description
C3536 2113740F31 15
C3537 2113740F33 18
C3539 2113740F21 5.6
C3541 2113743M08 0.022pF
C3542 2113743L05 330pF
C3543 2113743M08 0.022pF
C3544 2113743L05 330pF
C3546 2113743L05 330pF
C3547 2113743M08 0.022pF
C3550 2113743N23 7.5pF
C3551 2113743N46 68pF
C3552 2113743N44 56pF
C3560 2311049A07 1.0uF
C3561 2113743M08 0.022pF
C3562 2113743L29 3300pF
C3563 2113743L29 3300pF
C3564 2113743L01 220pF
C3565 2113743E07 0.022uF
C3566 2113743N50 100pF
C3567 2113743L05 330pF
C3568 2113743L29 3300pF
C3569 2113743M08 0.022pF
C3570 2113743L05 330pF
C3571 2113743L09 470pF
C3701 2113743L41 0.01uF
C3702 2113743L41 0.01uF
C3703 2113743L41 0.01uF
C3704 2113743L41 0.01uF
C3705 2113743E20 10 uF
C3706 2311049J11 4.7uF
C3707 2113743N34 22pF
C3708 2113743M24 0.1uF
C3709 2113743M24 0.1uF
C3710 2104993J02 2.2uF
C3711 2311049A69 10uF
C3712 2113743M24 0.1uF
C3713 2311049A09 2.2 uF
C3714 2311049J11 4.7uF
C3715 2113743L09 470pF
C3721 2113743E20 10 uF
C3722 2113743E20 10 uF
C3724 2311049A08 1uF
C3726 2113743N24 8.2pF
C3727 2113743N50 100pF
C3731 2113743L41 0.01uF
C3732 2113743L41 0.01uF
C3733 2104993J02 2.2uF
C3734 2113743L41 0.01uF
C3742 2113743L01 220pF
C3743 2113743L01 220pF
C3744 2113743L01 220pF
C3745 2113743L01 220pF
C3746 2113743L01 220pF
C3752 2113743L17 1000pF
C3753 2311049A56 4.7uF
C3754 2113743M24 0.1uF
Circuit
Ref
Motorola Part
No.
Description
C3755 2104993J02 2.2uF
*C3761 2113743N44 56.0pF
*C3762 2113740F63 330pF
*C3763 2113743N08 1.6pF
C3801 2113743N18 4.7pF
C3803 2113743L17 1000pF
C3804 2113743E20 10uF
C3805 2113743N18 4.7pF
C3806 2113743N50 100pF
C3808 2113743N30 15pF
C3809 2113743N36 27pF
C3811 2113743M24 0.1uF
C3812 2113743M24 0.1uF
C3813 2113743L41 0.01uF
C3815 2113743L17 1000pF
C3816 2113743N22 6.8pF
C3818 2113743E07 0.022uF
C3821 2113743L41 0.01uF
C3822 2113743L17 1000pF
C3823 2113743L41 0.01uF
C3824 2113743N44 56pF
C3825 2113743N30 15pF
C3826 2113743N18 4.7pF
C3827 2113743E07 0.022uF
C3828 2109720D01 0.01uF
C3829 2109720D01 0.01uF
C3830 2113743N46 68.0pF
C3832 2113743L17 1000pF
C3833 2113743N18 4.7pF
C3834 2113743N44 56pF
C3835 2113743N22 6.8pF
C3836 2113743N30 15.0pF
C3842 2113743L17 1000pF
C400 2113743L41 0.01uF
C401 2113743M24 0.1uF
C402 2113743M24 0.1uF
C403 2113928D08 10uF
C407 2113928N01 0.1uF
C408 2113743N50 100pF
C409 2113743M24 0.01uF
C410 2113928N01 0.1uF
C411 2113743M24 0.01uF
C414 2113743M24 0.01uF
C415 2109720D01 0.01uF
C416 2113928N01 0.1uF
C419 2113743L41 0.01uF
C420 2113743L41 0.01uF
C421 2113928N01 0.1uF
C422 2113743M24 0.01uF
C423 2113743N50 100pF
C424 2311049A59 10uF
C425 2113743M24 0.01uF
C426 2113743N50 100pF
C427 2113743N50 100pF
C428 2113743M24 0.01uF
C429 2113743M24 0.01uF
Circuit
Ref
Motorola Part
No.
Description
