A - 6 MC75A Enterprise Digital Assistant Integrator Guide
MC75A Accessory Specifications
Single Slot USB/Serial Cradle
14 RS232_DSR
15 External_5.0V_Out
16 External DC In_5.4V
Table A-3
External Connector Pin-Outs (Continued)
Pin Description
Table A-4
Single Slot USB/Serial Cradle Technical Specifications
Feature Description
Dimensions Length: 14.54 cm (5.72 in.)
Width: 11.05 cm (4.35 in.)
Height: 9.10 cm (3.58 in.)
Weight 196 g (6.9 oz)
Input Power 12 VDC
Power Consumption 30 watts
Interface USB, Serial
Operating Temperature 0°C to 50°C (32°F to 122°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Charging Temperature 0°C to 40°C (32°F to 104°F)
Humidity 5% to 95% non-condensing
Drop 76.2 cm (30.0 in.) drops to vinyl tiled concrete at room temperature
Electrostatic Discharge (ESD) +/- 15 kV air
+/- 8 kV contact
