7 Related Documents
Compound 2-stage Screw Compressor 7.2 Parts Configuration Table
1612LSC Speed Increaser Type
7-5
7.2 Parts Configuration Table
Table 7-1 Configuration table of the parts
P/N Part name Part code No. Remarks
Quantity
52/62 53/63 54
1-1 Main Rotor Casing (1) CS00100-160L 160L**
1 1 -
1-2 Main Rotor Casing (2) CS00100-1612C 1612*SC
1 1 1
2-1 Hexagon Socket Head Cap Screw NB35412-040 M12×40
52 52 52
2-2 Hexagon Socket Head Cap Screw NB35414-040 M14×40
36 36 36
3-1 Alignment Pin NE2013-040 Φ13×40
4 4 4
3-2 Alignment Pin NE2016-040 Φ16×40
4 4 4
4-1 Hanger Bolt NB600-16 M16
1 1 1
4-2 Hanger Bolt NB600-12 M12
1 1 1
5-1 Suction Cover (1) CS00500-1612C1 1612**C
1 1 1
5-2 Suction Cover (2) CS00500-1612C2 1612**C
1 1 1
6-1 Gasket, Suction Cover (1) CS00600-160N 160***
1 1 1
6-2 Gasket, Suction Cover (2) CS00600-1612CN 1612**C
1 1 1
8 Spring Pin NE3204-010 Φ4×10
4 4 4
10-1A Plug NF06-010 R3/8
1 1 1
10-2A Plug NF06-008 R1/4
1 1 1
10-2B Plug NF06-010 R3/8
1 1 1
11-1 Bearing Head (3) CS01100-1612C3 1612**C
1 1 1
11-2 Bearing Head (2) CS01100-1612C2 1612**C
1 1 1
12-1 Gasket, Bearing Head (1) CS01200-160N 160***
1 1 1
12-2 Gasket, Bearing Head (2) CS01200-1612CN 1612**C
1 1 1
13 Hanger Bolt NB600-12 M12
1 1 1
14 Spring Pin NE3204-010 Φ4×10
4 4 4
15-1A Plug NF06-004 R1/8
1 1 1
15-1B Plug NF06-004 R1/8
1 1 1
15-1C Plug NF06-015 R1/2
1 1 1
15-1D Plug NF06-020 R3/4
1 1 1
17-2 Gasket, Bearing Cover (2) CS01700-1612CN 1612**C
1 1 1
18-1 Hexagon Socket Head Cap Screw NB35414-040 M14×40
24 24 24
18-2 Hexagon Socket Head Cap Screw NB35412-040 M12×40
26 26 26
19-1 Alignment Pin NE2013-040 Φ13×40
2 2 2
19-2 Alignment Pin NE2013-040 Φ13×40
2 2 2
20 Spring Pin NE3203-010 Φ3×10
1 1 1
21 Plug NF06-004 R1/8
1 1 1
22 Balance Piston Cover CS02200-1612C 1612**C
1 1 1
23 Gasket, Balance Piston Cover CS02300-1612CN 1612**C
1 1 1
24 Hexagon Socket Head Cap Screw NB35410-035 M10×35
12 12 12
25-1 Male Rotor (1)
CS02500-1612C1N
1612LSC
speed increaser type
1 1 1
26-1 Female Rotor (1)
25-2 Male Rotor (2)
CS02500-1612C2N 1612LSC
1 1 1
26-2 Feale Rotor (2)
27-1A Main Bearing /Side Bearing (1) A CS02700-1612C3
1612LSC
speed increaser type
1 1 1
27-1B Main Bearing /Side Bearing (1) B CS02800-1610C1 1610SLC/1612**C
1 1 1
27-2 Main Bearing (2) CS02700-125 125***
2 2 2
28-1 Main Bearing /Side Bearing (1) CS02800-1610C1 1610SLC/1612**C
2 2 2
28-2 Side Bearing (2) CS02800-125 125***
2 2 2
29-1A Snap Ring (1) C type Internal NG11-112 H112
1 1 1
29-1B Snap Ring (1) C type Internal NG11-102 H102
3 3 3
29-2 Snap Ring (2) C type Internal NG11-080 H80
4 4 4
30 Balance Piston CS03000-1612C 1612**C
1 1 1
