ND-45383 (E) CHAPTER 3
Page 103
Revision CD 1.0
Figure 3-28 Details of D
term
Connection
BX AX
IDF
CABLE PAIR
MODULAR CABLE
MODULAR 
BLOCK
(JACK)
H2 H1 G L2 E L1
BK Y R G
D
term
RB RA TB TA
MODULAR JACK
CHAMP Connector
Lead
