NEC NEAX 2400 ICS User Manual

CHAPTER 3 ND-45383 (E)
Page 40
Revision CD 1.0
3.2.3 When Mounting the DRU on the 19-inch Rack (Option)
Mount the DRU onto the 19-inch rack by referring to Figures 3-12 and 3-13.
Note: The 19-inch rack should be provided by the installer.
Figure 3-12 Installation of the DRU (When Mounting 4 Sets of DRU onto the 19-inch Rack)
2100 mm
(7'10" inches)
1958 mm
(7'5" inches)
BATT BOX UNIT (Special)
Batteries
DRU Mounting M.T.G
DRU
19-inch Rack (IEC Spec.)
Note: The battery and the BATT BOX ASSEM are Locally Provided.
