NETGEAR R6100 User Manual

Hardware Setup
10
R6100 WiFi Router
• WiFi On/Off button. Pressing and holding this button for two seconds turns the 2.4 GHz
and 5 GHz wireless radios on or off. If the Wireless LED is lit, the wireless radios are on.
If this LED is off, the wireless radios are turned off and you cannot connect wirelessly to
the router.
• WPS button.
You can use this button to use WPS to add a wireless device or computer
to your wireless network. The Wireless LED blinks blue when the router is trying to add
the wireless device or computer. The LED stays solid blue when wireless security is
enabled in the router.
Rear Panel
The rear panel has the connections and buttons shown in the following figure.
USB Ethernet Internet
Power On/Off
Power connector
port
LAN ports 1–4
Reset
buttonport
Figure 3. Router rear panel
The Reset button restores the factory settings. See Factory Settings on page 117.

NETGEAR R6100 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
USB version	2.0
Rack mounting	-
xDSL connection	No
Bandwidth (first)	2.4 GHz
Bandwidth (second)	5 GHz
USB ports quantity	1
WLAN data transfer rates supported	300, 867 Mbit/s
Ethernet LAN (RJ-45) ports	5
Security algorithms	WEP, WPA, WPA2-PSK
Flash memory	128 MB
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	60 mm
Width	180 mm
Height	170 mm
Weight	322 g
