NETGEAR R6100 User Manual

Advanced Home Settings
40
R6100 WiFi Router
not support WMM and applications that do not require QoS, are assigned to the best effort
category, which receives a lower priority than voice and video. WMM QoS is enabled by
default.
 To disable WMM QoS:
1. Select ADV
ANCED > Setup > QoS Setup.
2. Clear the Enable WMM check box for the band (2.4 GHz or 5 GHz).
3. Click the Apply button.
Set Up Bandwidth Control
 To set up the maximum uplink bandwidth:
1. Select ADV
ANCED > Setup > QoS Setup.
2. Leave the Enable WMM check boxes selected.
3. (Optional)
To prioritize Internet traffic, select the Turn Internet Access QoS On check box.
4. (Optional)
To detect the current uplink bandwidth, click the Check button.
This helps you to determinate the maximum bandwidth setting
5. Select the T
urn Bandwidth Control On check box.
6. Use one of these methods to specify the maximum bandwidth:
• To use the current uplink bandwidth, select the Uplink bandwidth radio button.
• Select the Automatically check Internet uplink bandwidth radio button.
7. Click the Apply button.

NETGEAR R6100 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
USB version	2.0
Rack mounting	-
xDSL connection	No
Bandwidth (first)	2.4 GHz
Bandwidth (second)	5 GHz
USB ports quantity	1
WLAN data transfer rates supported	300, 867 Mbit/s
Ethernet LAN (RJ-45) ports	5
Security algorithms	WEP, WPA, WPA2-PSK
Flash memory	128 MB
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	60 mm
Width	180 mm
Height	170 mm
Weight	322 g
