3. OPERATION
i
3
OPERATION
CONTENTS
3-1. Display and Key Functions ................................................. 3-1
1) Basic Measurement Screen (BMS) .................................................3-4
2) LCD Backlight, Reticle, LG, Sound and Contrast ............................3-5
3-2. Pre-Start................................................................................ 3-7
1) Input Point Name/Number...............................................................3-7
1. Inputting an Existing PT.......................................................................3-7
2. Inputting a New PT ..............................................................................3-7
3. Pressing [ENT] without a PT................................................................3-8
4. When a Wildcard (*) is Specified.........................................................3-8
5. When the [MSR] Softkey is Pressed ....................................................3-9
6. Inputting PT by [List] Softkey............................................................3-10
7. Inputting PT by [Stack] Softkey .........................................................3-10
2) How to Input a Code......................................................................3-11
1. Direct Input.........................................................................................3-11
2. Stack...................................................................................................3-11
3. Code List ............................................................................................3-12
4. Qcode..................................................................................................3-13
3) How to Input Feet-Inches...............................................................3-14
4) List Displays of Data/Jobs .............................................................3-15
5) About Jobs.....................................................................................3-16
3-3. Getting Started ................................................................... 3-18
1) Turn On the Instrument [PWR].................................................3-18
2) Turn Off the Instrument
[PWR] → [REC/
ENT
] ..........................3-19
3) Measuring Distances
[MSR1]/[MSR2].....................................3-20
1. Sighting a Prism Reflector..................................................................3-20
2. Measuring Distances...........................................................................3-21
3. Settings for Measurement...................................................................3-22
4) Switch Displays
[DSP]..............................................................3-23
1. Changing Display...............................................................................3-23
2. Customizing Items on the BMS..........................................................3-24
To Next Page
