3
2) LCD Backlight, Reticle, LG, Sound and Contrast
[ ]/[ ]
<4-switch window> <Contrast adjustment>
The LCD backlight can be turned ON/OFF by pressing the illumination key ( ).
Holding down the illumination key for one second opens a small window (4-switch
window) on any screen. The window includes Backlight, Reticle, Lumi-guide and
Sound ON/OFF switches as well as Contrast adjustment.
On the 4-switch window, press the [ENT] key or [1] to [4] to turn the switch
ON/OFF. The Up/Down arrow keys move the cursor among the four switches.
The Right/Left arrow keys change the window between 4-switch and the Contrast
adjustment screen. On the Contrast adjustment screen, use Up/ Down arrow keys to
change the contrast.
Press the [ESC] key to close the window.
1. Backlight
: Backlight OFF
: Backlight ON
2. Reticle
: Reticle light OFF
: Reticle light ON (minimum)
: Reticle light ON (medium)
: Reticle light ON (maximum)
3-5
