Connecting the Power Cord
WARNING
Make sure to use the specified power cord. Using a wrong power cord may result in
malfunctions or fire. This microscope is classified as subject to Class I protection
against electrical shock. Make sure it is connected to an appropriate ground terminal
(protective earth terminal).
For specifications of the power cord, refer to “VII. Specifications.”
Turn off the power switch on the microscope (flip it to the “ ” side).
Insert the plug of the power cord into the AC inlet on the back of the microscope. Then, securely
plug the power cord to the wall outlet.
IV. Assembly
18
Anti-static Treatment
Many parts of the microscope have anti-static finishes, which are very useful when observing
electrostatically sensitive specimens. The anti-static parts include: the LV100DA-U, the LV-
UEPI2A epi illuminator, the LV-TT2 eyepiece tube, the L-W 10x eyepieces, the 3x2 stage, the ESD
plate, the motorized universal quintuple nosepiece, and the objectives. The ground connection can
be taken through the 3-conductor power cord of the microscope. However, if the power of the
microscope is not used at all, for example an external light sources used instead, the ground
connection can be taken by connecting the grounding line to the grounding tap at the rear of the
microscope.
17
Installing Options
To install photomicrographic equipment or other separately sold accessory, refer to the system
diagram and the instruction manual for each accessory.
