Nikon Eclipse LV100DA-U User Manual

12
6
Rear View
This drawing depicts the Eclipse LV100DA-U microscope configured with the LV-UEPI2A epi
illuminator, the LV-TT2 eyepiece tube, the 3x2 stage, the lamp house for the episcopic illumination,
and the lamp house for the diascopic illumination
I. Part Name
LAMP
DC12V 50W
- High Temperature -
CAUTION !
HALOGEN 12V50W
Do not touch the lamphouse while the lamp is lit.
The surface of the lamphouse becomes hot when
the lamp is on.
Turn off the power and allow the lamp and lamp-
house to cool enough before replacing the lamp.
Wait for at least 30 minutes after turning off
the lamp
Use 12V50W HALOGEN lamp only.
1.
2.
3.
LV-LH50PC
JAPAN
652702
- High Temperature -
CAUTION !
HALOGEN 12V50W
Do not touch the lamphouse while the lamp is lit.
The surface of the lamphouse becomes hot when
the lamp is on.
Turn off the power and allow the lamp and lamp-
house to cool enough before replacing the lamp.
Wait for at least 30 minutes after turning off
the lamp
Use 12V50W HALOGEN lamp only.
1.
2.
3.
LV-LH50PC
JAPAN
652702
LAMP
DC12V 50W
ECLIPSE LV100DA-U
100–240V~ 1.2A 50/60Hz
MADE IN JAPAN
including interference that may cause
undesired operation.
This device complies with Part 15 of
the FCC Rules. Operation is subject
to the following two conditions:
(1) this device may not cause harmful
interference, and (2) this device must
accept any interference received,
921001
This Class A digital apparatus complies with
Canadian ICES-003.
Cet appareil numérique de la classe A est
confirme à la norme NMB-003 du Canada.
4N75
INSPECTION
EQUIPMENT
“CAUTION for heat” symbol
“CAUTION for heat” symbol
Lamphouse connector
for episcopic illumination
Input voltage indication
CAUTION label
CAUTION label
Power switch
AC inlet
Lamphouse connector
for diascopic illumination
Tap for grounding (M4)
