1 Introduction
4 Pulse Laser Station NPL-302 Series Instruction Manual
Parts of the Instrument 1.2
Figure 1.1 and Figure 1.2 show the main parts of the NPL-302 series instrument.
Figure 1.1 Pulse Laser Station NPL-302 series – Face-1
Optical sight
Telescope
Telescope
Diopter ring
Reticle plate
Plate level
Face-1
display/keyboard
Leveling base
clamp knob
Battery mounting
button
Battery pack
BC-65
Vertical tangent
screw
Vertical clamp
Upper plate
tangent screw
Upper plate clamp
The laser Safety Label shown
below is attached to the
underside of the keyboard
(Finder)
Carrying
handle
focusing ring
eyepiece
cover
