2. Program Change How to Use the Basic Program
18
NFS-640 Programming Manual P/N 51333:B 10/03/2003
How to Add a Device to the Program
You can also use the Autoprogram option to add addressable devices to the control panel program.
Note: When using the Autoprogram option with an existing program, the control panel does not change program
information for installed and programmed devices.
The following steps describe how to add a new detector at SLC address 1D147 with 10 detectors in the
existing program:
1. Physically install the addressable detector to SLC 1 at address 147 (for instructions, refer to the
NFS-640 Installation Manual and the installation document that comes with the detector).
2. From the “Basic Program” screen, press the 1 key to start Autoprogram. The Autoprogram Prompt
screen appears in the LCD display as the control panel identifies addressable devices. When
finished identifying addressable devices, the control panel displays information for the new
detector at SLC address 1D147 on the LCD display as shown below:
3. Press the
ENTER key to add detector 147 to the program with the default program information. If
you want to change the default information, use the programming keys to do so, then press the
ENTER key to add detector 147 to the program.
The Autoprogram Summary screen appears. You can verify addition of the detector to the program
by noting the new count of detectors as shown below:
4. Press the
ENTER key, then press the ESC key to save the program in memory and return to the “Basic
Program” screen).
How to Remove a Device from the Program
You can also use the Autoprogram option to remove addressable detectors and modules from the control
panel program.
Note: When using the Autoprogram option with an existing program, the control panel does not change program
information for installed and programmed devices.
The following steps describe how to delete a detector at SLC address 1D133 with 11 detectors
connected to SLC 1 in the existing program:
1. Disconnect and remove the detector from SLC 1 at address 1D133.
2. From the “Basic Program” screen, press the 1 key to start Autoprogram. The Autoprogram Prompt
screen displays while the control panel identifies addressable devices.
3. When finished identifying addressable devices, the control panel displays a screen, indicating a
missing detector at SLC address 1D133 as shown below:
4. Press the
ENTER key to delete detector 1D133 from the program.
The Autoprogram Summary screen appears. You can verify removal of the detector from the
PROGRM SMOKE(PHOTO) DETECTOR ADDR 1D147
03 __ __ __ __A8P8** 1D147
Note that the number of detectors increases (in this example
from 10 to 11) to show the addition of the detector to SLC 1.
L1:011Dets, 159Mods L2:159Dets, 159Mods
Panel Outputs: 64 Bells: 04
Type Code
SLC loop number
D (detector) or M (module)
Three-digit address (001-159)
PROGRM SMOKE (ION) DETECTOR ADDR 1D133
DEVICE NOT ANSWERING DELETE FR MEM?1D133
