2. Program Change How to Use the Basic Program
34
NFS-640 Programming Manual P/N 51333:B 10/03/2003
Annunciation Points
The control panel’s annunciation points are divided into 23 ACS selection groups of 64 points each. The
table below contains a list of these groups, what an annunciator displays when a group is selected, and
where to locate a definition of the 64 points within the group.
Table 12 ACS Selection Groups
Note: Refer to the VeriFire™ Tools programming utility for programming these annunciators.
ACS
Selection
Group
Annunciator Display Refer to
A 8 System points & Zones 1 - 56 Table 13 on page 35
B Zones 57 - 99, 9 F Zones, 8 R Zones, 4 NACs Table 14 on page 35
C Loop 1, Modules 1 - 64 Table 15 on page 36
D Loop 2, Modules 1 - 64 Table 16 on page 36
E Loop 1, Modules 65 - 128 Table 17 on page 36
F Loop 2, Modules 65 - 128 Table 18 on page 36
G Loop 1, Modules 129 - 159 (1 unused point)
Loop 2, Modules 129 - 159 (1 unused point)
Table 19 on page 37
H Loop 1, Detectors 1 - 64 Table 20 on page 37
I Loop 2, Detectors 1 - 64 Table 21 on page 37
J Loop 1, Detectors 65 - 128 Table 22 on page 38
K Loop 2, Detectors 65 - 128 Table 23 on page 38
L Loop 1, Detectors 129 - 159 (1 unused point)
Loop 2, Detectors 129 - 159 (1 unused point)
Table 24 on page 38
M Panel Circuits 1.1 to 8.8 (64) Table 25 on page 39
N 8 System Points & Zones 1-56 “ACS Selection Group
N” on page 40
O 8 System Points & Zones 1-56 “ACS Selection Group
O” on page 40
1 Programmable Annunciator #1 See Note
2 Programmable Annunciator #2 See Note
3 Programmable Annunciator #3 See Note
4 Programmable Annunciator #4 See Note
5 Programmable Annunciator #5 See Note
6 Programmable Annunciator #6 See Note
7 Programmable Annunciator #7 See Note
8 Programmable Annunciator #8 See Note
9 Programmable Annunciator #9 See Note
0 Programmable Annunciator #10 See Note
