Ochsner OTE 3 User Manual

BA_OTE 3+4_Endkunde_EN_V03_20170726.docx Page 29 of 52
temp.)
00-008 TWR temperature (HP
return temp.)
Heat pump return temperature (sensor TWR)
00-070 TQA heat source output
temp.
Heat source outlet temperature (sensor TQA), for
Air/Water heat pumps - evaporator temperature 2
00-071 TQE heat source input
temp.
Heat source input temperature (sensor TQE), for
Air/Water heat pumps - evaporator temperature 1
00-076 Actual compressor ro-
tational speed (RPS)
The current compressor speed is shown here (not acces-
sible with all heat pumps)
00-088 Flow temperature pas-
sive cooling (TPV)
Flow temperature for passive cooling
02-080 Operating cycles
Display of the absolute heat pump switching cycles
02-081 Operating hours
Display of the absolute heat pump operating hours
21-002 Flow rate heat sink
Current flow rate in the heat use system
21-090 Flow rate heat source
Current flow rate in the heat source system (only for
heat source brine or water)
23-001 Heating energy
Display of the absolute used energy in kWh
23-004 De-icing energy
Display of the absolute used energy in kWh
23-005 Cooling energy
Display of the absolute used energy in kWh
23-066 Hot water energy
Display of the absolute used energy in kWh
23-010 Heating energy
Display of the absolute used energy in MWh
23-011 De-icing energy
Display of the absolute used energy in MWh
23-012 Cooling energy
Display of the absolute used energy in MWh
23-013 Hot water energy
Display of the absolute used energy in MWh
8.3 Relay test
The output status can be seen in the relay test.
Output status Description
01-022 Heat generator pump
0 … 100%
01-076 Setpoint rotational speed compres-
sor
0 … 100%
01-077 Heat source pump/fan
0 … 100%
