Ochsner OTE 3 User Manual

BA_OTE 3+4_Endkunde_EN_V03_20170726.docx Page 50 of 52
18 Annex
18.1 Technical Data Control
Description
Data OTE3 (SE6024WPC)
Data OTE4 (SE6034WPC)
Operational voltage
~ 230 V (AC) ± 10%, 50 Hz
Current draw stand-by
< 11W
5W
Maximum current draw
max. 16 W
max. 15W
Measurement circuit voltage
24V
Ambient temperature in operation
0°C to 50°C
Ambient temperature storage
-20°C to 60°C
Humidity in operation
max. 85% relative humidity, not condensing
Sensor wiring, length, cross section
max. 100m, min. 0,75mm²
eBus:
• Bus wiring, length, cross section
• Loading
2-wire Bus, twisted, max. 50m, min. 1mm²
24V; max. 80mA (constant current)
Switching rating outputs (relays)
~230 VAC 6(2) A, 50 Hz
Set value input
0 to10 VDC, non-floating, current max. 10mA
Power reserve timer
Ca. 300 days
Ca. 200 days
Dimensions of the control (HxWxD)
320 mm x 150 mm x 61 mm
18.2 Temperature sensor
All control temperature sensors have the same characteristic NTC 5000Ω at 25°C (see Ta-
ble).
Temp
[°C]
Resistance
[Ω]
Temp
[°C]
Resistance
[Ω]
Temp
[°C]
Resistance
[Ω]
Temp
[°C]
Resistance
[Ω]
-20
48322.7
8
10949.6
30
4029.2
58
1339.6
-18
43071.6
10
9942.9
32
3702.3
60
1246.2
-16
38447.9
12
9039.2
34
3405.3
62
1160.2
-14
34370.5
14
8227.2
36
3135.1
64
1081.0
-12
30769.4
15
7852.3
38
2889.1
65
1043.7
-10
27584.4
16
7496.6
40
2664.8
66
1008.0
-8
24763.2
17
7159.0
42
2460.2
67
973.6
-7
23474.8
18
6838.4
43
2364.7
68
940.5
-6
22260.9
19
6534.0
44
2273.4
69
908.8
-4
20038.1
20
6244.9
46
2102.6
70
878.3
-2
18061.0
21
5970.1
48
1946.3
71
848.9
0
16300.0
22
5709.0
50
1803.2
72
820.7
2
14729.4
24
5224.6
52
1672.1
74
767.5
4
13326.8
26
4786.3
54
1551.7
76
718.2
6
12072.6
28
4389.2
56
1441.2
78
672.6
