44015503TH Rev. 1
155 /
Oki Data CONFIDENTIAL
6. CLEANING
6.3 Pick-up roller cleaning
The pick-up rollers must be cleaned when a vertical line occurs on printed output.
Note! U
se a soft cloth to clean the pick-up rollers so as not to damage their surfaces.
Paper feed roller and pad cleaning
When frequent ‘SLIDE OUT TRAY-PAPER JAM [tray name]’ messages occur, clean the
paper feed rollers and pad of the tray identified by the tray name in the message.
(1) Pull out the paper cassette of the tray being displayed.
(2) Wipe the paper feed rollers (large and small) with a cloth tightly wrung out with
water.
(
3) Wipe the pad of the paper cassette with a cloth tightly wrung out with water.
Note! W
hen frequent ‘OPEN COVER-PAPER JAM-FRONT COVER’ messages
occur, clean the paper feed roller of the multi-purpose tray in the same manner
as described above.
Paper feed roller (large)
Paper feed roller (small)
To Next Page
