44015503TH Rev. 1

231 /

Oki Data CONFIDENTIAL

7. TROUBLESHOOTING PROCEDURE

7.7 Paper cassette switches versus Paper size correspondence table

Bit Number Dial Indication Size (OEL) Dial Indication Size (ODA)

1 2 3 4 T

RAY1 TRAY2/3 TRAY1 TRAY2/3

H H H H No cassette No cassette No cassette No cassette

L L L L A4 A4 A4 A4

H H L L A6 SEF A4 SEF A4 SEF

L H L L A5 SEF A5 SEF A5 SEF A5 SEF

L H H L LTR LEF LTR LEF LTR LEF LTR LEF

H H H L Tabloid Tabloid LTR SEF LTR SEF

H L H L B5 LEF B5 LEF Tabloid Tabloid

H L H H B4 B4 LEGAL LEGAL

L L L H A4 SEF A4 SEF EXEC EXEC

L L H L A3 A3 A3 A3

L L H H Reserved Reserved Reserved Reserved

L H L H Reserved Reserved Reserved Reserved

H H L H Reserved Reserved Reserved Reserved

H L L H Reserved Reserved Reserved Reserved

L H H H Reserved Reserved Reserved Reserved

H L L L Reserved Reserved Reserved Reserved

Press of SW: L
