5.1.2.5 Test Print
This self-diagnostic routine is used to print the test pattern in the PU. Other test patterns are
stored in the controller.
1. Continue to press the [MENU+] and [MENU-] keys until “TEST PRINT” appears at
the top row of the display, and the system is in the self-diagnosis (Lever 1) mode.
The [MENU+] key = Increment Test Item / the [MENU-] key = Decrement Test Item.
2. Press the [ENTER] key only for the setting item applied for test printing appears at
the bottom of the display. Press the [MENU+] and [MENU-] keys until the applicable
item appears. The [MENU+] key = Increment Item / the [MENU-] key = Decrement
Item. (Go to Item 5 to [Default Setting] if setting of each item is unnecessary.)
3. Press the [ENTER] key for the setting item to appear on the top row of the display
and the setting value to appear at the bottom row of the display. Press the [MENU+]
key for the setting value to increment. Press the [MENU-] key for the setting value to
decrement (the final display setting value is applied). Accordingly repeat item 3.
*1 TRAY 2 to TRAY 5 and DUPLEX will be displayed only when their respective units are installed.
*2 If the finisher is not installed, “OUTPUT BIN” is displayed and only the output bin is selectable.
• Presets: FACE DOWN/FACE UP Default: FACE DOWN
* These settings are valid in the test mode only (they will not be written to the EEPROM).
Display Setting value Function
PRINT EXECUTE – Press [Enter] to start printing or [CANCEL] to stop printing (each page).
TEST PATTERN 0 0: Blank page1 to 7: See the “Test Print Pattern” table (pattern printing).
8 to 15: Blank page
CASSETTE TRAY1 Choose a paper feeder.
TRAY2 *1
TRAY3 *1
TRAY4 *1
TRAY5 *1
MPT
PAGE 0 Set the number of test print pages. Press [ONLINE] to move the cursor
to the digit to be edited. Press[MENU_] to increase the set value, and
[MENU_] to decrease the set value.
COLOR ON Choose Color or Monochrome.
OFF
DUPLEX *1 3 PAGES STACK Prints on both sides of a stack of 3 sheets.
OFF Turns off duplex printing.Prints on both sides of one sheet. Turns the job
offset function on and off.
1 PAGES STACK
JOB OFFSET OFF Turn the job offset function on and off.
ON
FINISHER *2 OUTPUT BIN Choose an output bin.
PUNCH Turns the punch mode on and off.
OFFSET Turns the offset mode on and off.
STAPLE Choose the staple location.
STAPLE PAGE Set the number of sheets to be stapled (0 to 50).
INVERT Turns the invert mode on and off.
TEST PATTERN
1
